SVC-3 (TNS) Three-Phase Servo Motor Type Voltage Stabilizer
Industrial-grade three phase voltage stabilizers for 380V/415V/480V systems. Advanced servo & IGBT technology with automatic phase balancing, 1.5KVA-3000KVA capacity. Trusted by manufacturers in 130+ countries since 2008.
A three-phase voltage stabilizer holds a 380 V or 400 V supply inside a fixed output band so motors, CNC spindles, and production lines see steady voltage on all three phases. Choose by input window first, then capacity. YIY's three-phase servo lines run from 1.5 kVA (SVC-3, PRO-3) to 3000 kVA (SBW), with regulation accuracy of ±3% (SVC-3, PWR-3, SBW) or ≤2% (PRO-3). Size from connected kVA plus a margin for motor starts, and check the low-input current before ordering. 415 V and other voltages are built to order: confirm the input window in writing. Need help? Request a three-phase stabilizer quote.
Selection guide
Start from your measured input window, not the nameplate voltage. A servo stabilizer keeps output kVA constant, so the current it draws rises as input sags; that low-input current is what your cable and breaker must carry.
| Capacity | Current per phase at 415 V | At 380 V | YIY series listed at this size |
|---|---|---|---|
| 15 kVA | 20.9 A | 22.8 A | SVC-3, PRO-3 |
| 30 kVA | 41.7 A | 45.6 A | SVC-3, PRO-3 |
| 60 kVA | 83.5 A | 91.2 A | SVC-3, PRO-3, PWR-3, SBW |
| 100 kVA | 139.1 A | 151.9 A | SVC-3, PRO-3, PWR-3, SBW |
| 200 kVA | 278.2 A | 303.9 A | SBW |
| 500 kVA | 695.6 A | 759.7 A | SBW |
Current per phase: I = kVA × 1000 ÷ (√3 × VLL). At 415 V, I = kVA × 1000 ÷ (1.732 × 415).
Unbalance: % unbalance = maximum deviation from the average ÷ average × 100. NEMA MG 1 keeps voltage unbalance at the motor terminals to 1%, and current unbalance typically runs 6–10 times that figure (U.S. DOE Tip Sheet #7). Worked example: three phase current unbalance formula.
| Series | Listed input | Listed output |
|---|---|---|
| SVC-3 / PRO-3 | 278–433 V | 380 V; SVC-3 ±3%, PRO-3 ≤2%; or customized |
| PWR-3 (EU version) | 285–475 V (±25%) or 266–494 V (±30%) | 380 V or 400 V ±3% |
| PWR-3 (US version) | 166–250 V | 208 V or 220 V ±3% |
| SBW (50 kVA+) | 304–456 V | 380 V ±3% |
PWR-3 models: five three-phase ratings, 45K, 60K, 100K, 120K and 150K, with output of 36, 48, 80, 96 and 120 kW respectively; ±3% regulation and 98% efficiency.
For India's 415 V / 50 Hz plants, these 380 V catalogue windows don't transfer automatically. Ask for the 415 V build's input window, protection set points, and output tolerance on the quotation.
Air-cooled cabinets suit clean electrical rooms. Dusty or humid sites need a sealed enclosure: the SBW-F IP54 cabinet is the YIY option listed for that. Oil cooling is usually specified on large outdoor units; compare both in oil-cooled three-phase servo stabilizer guidance.
Clamp each phase under production load, average the three readings, and divide the largest deviation by that average. Repeat after rolling the motor leads one position: if the high reading follows the supply line, the cause is upstream.
At 415 V it carries about 27.8 A per phase. Total the connected kVA of the machines it will feed, add a margin for motor starts, and check motor starting current with the supplier before choosing 20 kVA over 30 kVA.
SVC-3 and PRO-3 are listed as 3-phase 4-wire with a 3-wire option; SBW is listed as 4-wire. Tell the supplier whether your loads use the neutral before you order.
No. A stabilizer corrects voltage; motor protection relays still have to trip on phase loss and excessive unbalance. Keep both in the panel design.
Logged minimum and maximum line voltage, connected kVA by phase, largest motor and its starting method, required output tolerance, enclosure and site conditions, and the output voltage (380, 400 or 415 V).
Yes, voltages outside the 380 V catalogue are built to order. Ask for the input window and protection set points of the exact build on the quotation.
Request a three-phase stabilizer quote with your voltage log and load list.
| Series | Type | Power Range | Input Voltage (European) | Input Voltage (American) | Output Accuracy | Response Time |
|---|---|---|---|---|---|---|
| SVC-3 | Servo | 1.5KVA-100KVA | 278V-433V/152V-228V | N/A | ±3% | 3-6s |
| PRO-3 | High-Precision Servo | 1.5KVA-100KVA | 278V-433V/152V-228V | N/A | ≤2% | 5s |
| PWR-3 | High-Power Servo | 45KVA-150KVA | 285V-475V/266V-494V | 166V-250V | ±3% | 5s |
| SBW-F | Industrial Heavy-Duty | 150KVA-3000KVA | 304V-456V/285V-475V/266V-494V | 480V±16% | High Precision | 10s |
| SBW | Conventional Industrial | 50KVA-3000KVA | 304V-456V | N/A | ±3% | 3-6s/3-6min |
